In a University of Kentucky laboratory, three small spacecraft stand-ins slid throughout low-friction air tracks, nudging and pulling each other with out thrusters, propellant, or bodily contact.
Instead, they used fastidiously timed magnetic fields, a way that might sooner or later assist future satellite tv for pc swarms maintain exact formations in house with out consistently burning gasoline.
The NASA and Air Force-backed research, set to be revealed in the September 2026 version of Aerospace Science and Technology, marks a step towards what researchers name electromagnetic formation flying, a proposed technique for controlling the relative positions of satellites utilizing onboard coils moderately than typical propellant-based thrusters.
In the research, researchers demonstrated a decentralized, three-satellite management system that used alternating magnetic field forces to keep up formation with centimeter-level precision, providing a attainable pathway for future space telescopes, interferometers, gravity-wave detectors, and different distributed spacecraft missions.
“Spacecraft formation flying can advance a variety of space technologies such as distributed-aperture telescopes, gravity-wave detectors, and interferometers,” researchers write. “One challenge for spacecraft formation flying is that traditional propellant thrusters eventually deplete, and they can contaminate sensitive spacecraft components.”
The research, authored by scientists from the University of Kentucky’s Department of Mechanical and Aerospace Engineering, focuses on a longstanding drawback in spacecraft engineering.
Many future missions might not depend on a single large spacecraft, however as a substitute on teams of smaller satellites flying in fastidiously organized formations. If these satellites can preserve their spacing and orientation with excessive precision, they may operate collectively like a a lot bigger scientific instrument.
For instance, a distributed-aperture telescope may use a number of spacecraft separated by fastidiously managed distances to realize observing capabilities that is perhaps troublesome or not possible with a single monolithic telescope.
Similar formation-flying ideas have been proposed for space-based interferometers and extra missions by which the relative positions of spacecraft are central to mission efficiency.
However, maintaining a number of satellites in formation isn’t straightforward. Standard spacecraft depend on thrusters, which eat restricted propellant. Over time, that gasoline runs out, limiting mission length and maneuverability. Thruster plumes may contaminate delicate devices, a priority on spacecraft carrying delicate optical, scientific, or electromagnetic sensors.
However, electromagnetic formation flying, or EMFF, provides a special risk. Each spacecraft carries electromagnetic coils. When electrical present flows by means of these coils, they create magnetic fields. Those fields work together with magnetic fields created by close by spacecraft, producing engaging or repulsive forces that may alter the satellites’ positions relative to at least one one other.
Put merely, the satellites can push or pull on one another utilizing magnetism.
The concept isn’t completely new. Previous work has explored electromagnetic formation flying between two spacecraft, together with experiments utilizing direct-current-driven coils.
The drawback turns into a lot more durable when the formation consists of three or extra satellites. In that case, each satellite tv for pc’s magnetic area can work together with the others, creating an internet of coupled forces that turns into more and more troublesome to manage as the formation grows.
The new research approaches that drawback utilizing alternating magnetic area forces, or AMFF. Rather than driving the coils with regular direct present, the researchers use sinusoidal currents at particular frequencies.
The key perception is that two satellites generate a nonzero time-averaged interplay pressure solely when their magnetic moments alternate at the similar frequency. If they don’t share a frequency, the common pressure between them is negligible.
That frequency-matching method successfully permits the system to pair satellites electromagnetically. One pair can work together at one frequency, whereas one other pair interacts at a special frequency.
By adjusting the amplitude of every sinusoidal sign, the satellites can management the energy of the pressure between every pair with out requiring a centralized controller to unravel the complete formation’s movement without delay.
“Only pairs with a common frequency can generate a nonzero time-averaged intersatellite force, and that force is determined solely by the amplitudes at the common frequency,” researchers write. “The method in this paper is decentralized, which means that each satellite has access to measurements of its position and velocity relative to only its local neighbor satellites.”
Centralized management can work in smaller programs, however it may well flip computationally clumsy as satellite tv for pc formations develop. A scalable system would want every spacecraft to make native choices based mostly on close by neighbors, moderately than requiring a single controller to calculate each pressure throughout the complete formation.
To take a look at the concept, the researchers constructed a ground-based experimental platform utilizing three customized electromagnetic actuation system models positioned on linear air tracks.
The air tracks allowed the models to maneuver with low friction, simulating one-dimensional relative movement between satellites. Each unit included an electromagnetic coil, batteries, energy electronics, an Arduino Due microcontroller, wi-fi communication {hardware}, and laser range-finding sensors for measuring relative place.
In the three-satellite setup, the heart unit was pushed by a sum of two sinusoidal currents, whereas every outer unit was pushed by a type of frequencies. This allowed the heart unit to work together independently with every outer unit, demonstrating the central premise of frequency-multiplexed magnetic management.
In closed-loop experiments, the three-satellite system achieved formation in lower than 30 seconds. The most steady-state formation error was lower than plus or minus 0.01 meters, or about 0.4 inches. The imply steady-state formation error was lower than plus or minus 0.001 meters, or about 0.04 inches.
Those numbers show that the technique did greater than produce a magnetic tug in a lab. It allowed a number of models to settle right into a desired formation utilizing native suggestions and alternating magnetic fields, whereas avoiding the coupling drawback that has restricted electromagnetic management for bigger formations.
The researchers additionally in contrast the experimental outcomes with laptop simulations. While the simulations usually matched the noticed habits, the staff famous some variations brought on by real-world {hardware} elements, together with sensor interference, present saturation, attainable misalignment, airflow disturbances alongside the air tracks, and unmodeled magnetic results.
Those caveats are essential. This was not a spaceflight demonstration, and the system was examined solely in a single dimension. Real spacecraft would function in a much more complicated atmosphere, the place microgravity, radiation, excessive temperature swings, atmospheric drag in low Earth orbit, gravitational forces, Earth’s magnetic area, and tools restrictions would all matter.
Researchers additionally notice that conventional thrusters should still be wanted for orbit upkeep, orbit transfers, or controlling the total heart of mass of a satellite tv for pc formation.
In essence, this isn’t a substitute for all spacecraft propulsion. It is best understood as a possible propellantless method for controlling the relative positions of satellites as soon as they’re already in orbit and working as a part of a formation.
Still, that limitation doesn’t diminish the attainable influence. If electromagnetic formation flying might be scaled and tailored for actual spacecraft, it may scale back propellant calls for for future distributed missions. That may prolong mission lifetimes, scale back contamination hazards to delicate devices, and allow spacecraft formations extra versatile than at the moment’s architectures.
The analysis was supported partly by the National Aeronautics and Space Administration (NASA), the National Science Foundation, and the Air Force Office of Scientific Research.
The funding combine displays the twin scientific and strategic pursuits in the work. NASA has clear causes to discover exact formation flying for future house observatories and scientific missions. The Air Force, in the meantime, has an apparent curiosity in satellite tv for pc coordination, maneuverability, and resilient distributed house programs.
The research’s most intriguing contribution could also be its demonstration that magnetic-field-based satellite tv for pc management might be each decentralized and scalable.
Rather than treating a multi-satellite formation in a single sophisticated system that have to be managed from the high down, AMFF permits every satellite tv for pc to handle interactions with its neighbors utilizing assigned frequencies. That may turn out to be more and more helpful as house missions transfer towards constellations, swarms, and distributed architectures.
Researchers warning that extra work might be wanted to maneuver past one-dimensional air-track experiments and towards three-dimensional testing, extra sensible sensing and management {hardware}, and, ultimately, on-orbit validation.
Additional coils could be wanted for three-dimensional place management, and relative angle management may require extra actuation frequencies for every interacting satellite tv for pc pair.
Nevertheless, the laboratory outcomes present that the underlying idea works in a three-body system, which is precisely the place the exhausting half begins.
Two satellites can pull or push on one another comparatively simply. Three satellites introduce the coupling drawback that makes electromagnetic formation flying troublesome. By demonstrating three-satellite management with alternating magnetic fields, the research delivers experimental proof that the frequency-based resolution can work.
For forthcoming house missions, that could possibly be a significant step. The subsequent technology of telescopes and orbital devices might not all the time be constructed as single monumental spacecraft. They could also be assembled nearly, with a number of satellites flying collectively as one coordinated machine.
If so, maintaining these satellites exactly organized with out losing propellant may turn out to be one in all the enabling applied sciences of future astronomy, Earth remark, and nationwide safety house programs.
“This article presented a 3-satellite experimental demonstration of decentralized EMFF using AMFF,” researchers conclude. “The settling time and steady-state formation error achieved in these experiments demonstrate that this approach is most likely capable of meeting requirements for satellite constellation reconfiguration and maintenance, thereby addressing the need for propellant-free formation flying.”
