Demand for lithium has surged in recent times as lithium-ion batteries energy more and more extra of our world. And but, at the same time as locations just like the U.S., Europe, and Australia have ample lithium sources inside their borders, China dominates international lithium refining. The greatest hurdle to tapping into the U.S. and Australia’s lithium is getting it out of exhausting rock minerals in a kind that’s helpful.
Extracting lithium from exhausting rock right this moment is an energy- and waste-intensive course of that’s typically far costlier than getting lithium from brine water, which additionally has main environmental drawbacks. Currently, lithium exhausting rock extraction entails baking the rock at over 1,000 Celsius and chemically leaching it to extract lithium. The relaxation of the rock is discarded.
Now, a group of researchers from MIT and elsewhere has developed a low-temperature course of for extracting battery-grade lithium from the most typical sort of lithium-bearing mineral. The course of makes use of a liquid reagent to dissolve the rock into the helpful kinds of its constituent components: not simply battery-ready lithium salts, but in addition smelter-grade alumina and cement-ready silica. After the minerals are extracted, the solvent and reagent may be recovered and used once more so waste ranges strategy zero.
The researchers estimate the closed-loop course of is half the fee of conventional lithium exhausting rock extraction and will make it cost-competitive with extracting lithium from brine water.
A paper describing the method was published today in Science. The researchers have already begun commercializing the know-how by way of an MIT spinout, Rock Zero.
“By 2040, we need to quadruple production of lithium globally, which amounts to hundreds of new lithium producing assets,” says creator Camden Hunt, a former mission supervisor in MIT’s Center for Electrification and Decarbonization of Industry. “Hard rock is abundant; you can find it everywhere. But most hard rock refining is done in China. Our central thesis is if you can find an easier way to crack the rock, get lithium out, and make battery-grade lithium salts, you can change the lithium market. It aligns with the recent push to onshore production of critical minerals in the U.S.”
Joining Hunt on the paper are former MIT postdoc Benjamin Mowbray; PhD candidate Kalyn Fuelling; MIT undergraduate Jacqueline Prawira; Khashayar Jafari, a former senior analysis scientist on the MIT inexperienced cement spinout Sublime Systems; and Yet-Ming Chiang, MIT’s Kyocera Professor of Materials Science and Engineering.
From loos to batteries
The analysis has its roots in a toilet renovation. About 25 years in the past, as Chiang made a journey to a ironmongery shop to search for one thing that will flip clear glass blocks translucent, he came across a glass etching cream that works by “eating away” on the floor of the glass. The lively ingredient turned out to be ammonium fluoride.
More just lately, as Chiang was brainstorming methods to chemically break aside essentially the most ample lithium-bearing mineral, spodumene, he thought again to that etching cream. Spodumene, like glass, consists largely of silica. Conventional chemistry-based strategies for extracting metals from ores preferentially dissolve extra reactive parts and depart behind a silica-enriched residue as a result of of the energy of silicon-oxygen bonds. By designing their course of to use a combination of water and ammonium fluoride, the researchers are ready to dissolve silica first, reversing the method.
The researchers confirmed they may dissolve spodumene rock at room temperature, which represented a breakthrough over conventional processes requiring excessive warmth. But it was nonetheless solely step one to a closed-loop system that produced helpful supplies.
“Dissolving silica is the hard part in mining,” Mowbray says. “The next question was how do we apply it to impactful mineral processing problems?”
The mineral spodumene is principally made up of three elements: lithium, aluminum, and silica. Mowbray and Hunt, who each have their PhDs in chemistry, started exploring methods to refine these elements individually after they had been damaged aside within the ammonium fluoride answer.
First, the researchers remoted lithium fluoride, a helpful enter for widespread electrolyte supplies utilized in batteries. Chiang, who has based a number of battery corporations over his multi-decade profession at MIT, subsequent requested the analysis group if they may isolate lithium hydroxide and lithium carbonate, two lithium salts helpful for making battery cathodes. The researchers went again to the lab and located they may make each by creating new processes, some of which concerned including carbon dioxide or sodium carbonate. Chiang tasked the analysis group with a related problem for the aluminum half of the rock, which was remoted utilizing a high-temperature separation technique, after which silica, which was remoted by precipitation.
“First our goal was to produce these products, then there were additional steps of characterizing their purity and properties and making sure our products met the specifications for target markets,” Mowbray explains. “For the lithium salts, we identified the purity specifications for battery-grade lithium carbonate, the most widely used lithium salt. For the silica, we wanted it to be used as a cement additive, so we did cement reactivity tests and eventually created cubes of cement from it for strength testing using industrial methods. For aluminum, we targeted smelter-grade aluminum. If any product didn’t meet the target specs, you’d end up with a waste stream.”
The researchers then developed a course of to reuse the ammonium fluoride and water that begins the response.
“We’re able to dissolve the rock with the spodumene in it, and that liberates all the elements, including the aluminum and lithium,” Chiang says. “The silica is in the solution, but on the way to making ammonium fluoride, ammonia gas also comes off. If that ammonia gas is then reapplied, it precipitates the silica again. That sequence gives us back the starting ammonium fluoride. That’s why it’s a circular process.”
The researchers efficiently processed 17 totally different spodumene rock sources, displaying its widespread applicability utilizing rocks all over the world.
“You’ve heard of nose-to-tail eating?” Chiang says. “We refer to this as nose-to-tail mining. Our researchers came to MIT to look for impactful problems to work on in sustainability. With their skill sets, it was just a matter of setting them loose on this problem. We went through all these steps, and for each one, I’d just say, ‘Can you do this next step?’ And a week or two later they’d say, ‘Okay, we’ve shown we can do that.’ That’s how this entire process got built.”
Scaling the method
Chiang additional challenged his analysis group to consider the industrial feasibility of their new system.
“Once we had these core operations worked out, Yet encouraged us to do some math,” Mowbray explains. “Is there enough spodumene in the world to supply 100 terrawatt-hours of battery production? The follow up was: If you supply all the world’s batteries with this process, what are the volumes of the co-products? Do they match global commodity markets? Then we started looking at the cost of the reagents, the cost of the energy, equipment. We started gaining conviction that this could have a big impact.”
The work has particular significance for Mowbray, who grew up in a historic mining city in rural British Columbia.
The researchers labored with MIT’s Technology Licensing Office to spin out their firm, Rock Zero, which is now positioned at The Engine and scaling up the system.
“We believe this approach is the lowest-energy, lowest-cost way of getting lithium not only out of hard rock, but period,” Chiang says. “That’s what’s motivating us to scale this. It will enable the energy transition through batteries that use lithium. This was one of the goals of The Climate Project at MIT — to work on projects that, within a short number of years, could transition from the lab to commercialization and impact.”
The work was supported, partially, by the Department of Energy Advanced Research Projects Agency-Energy (ARPA-E), the MIT Climate Grant Challenges program, and the National Science Foundation. The work made use of MIT.nano services.
